SEAQUEST

Performance Grade Expanded Vinyl

Designed specifically for All Types of Marine and Outdoor Applications.  All colors available in both Expanded Vinyl and Roll 'N Pleat.  High performance vinyl delivers durability, strength and colors.
General Information
54" Wide Cold Crack - 10° F
Expanded Vinyl: 40 Yard Rolls UV Resistant (1000 Hours)
Roll 'N Pleat: 10-20 Yard Rolls Mildew Resistant Treated Face and Back
32 Ounces Per Linear Yard Clean with Mild Soap and Water

Manufactured to meet the following flammability* codes:

  • California Fire Code Technical Bulletin 117, Section E

  • Motor Vehicle Safety Standard 302

  • UFAC Class 1

  • May comply with California 133 when tested with suitable components

* This term and any corresponding data refer to typical performance in the specific tests indicated and should not be construed to imply the behavior of this or any other material under actual fire conditions.
Recommended Applications
Marine and Outdoor Seating
Trim/Door Panels
Auto Trim
RV/Van Upholstery
Dinette/Casual Dining
Lounge
Hospitality
HealthCare
Contract
  Office
Education
Product Features
Strong and durable
Easily maintained
Resistant to color fading
Easily tailored
Soft and supple
33 beautiful colors
Deep grain leather styling
Cleans easily with mild soap and water
Mildew treated face and back
UV resistant (1000 Hours)
-10 º F cold crack

Spirit Millennium
Color truly comes to life in Spirit Millennium from Naugahyde. Designed with the colors of the new generation, Spirit Millennium represents a generously rich palette of 85 beautiful colors including new directional soft tones and pastels - and the classics that made Spirit pattern the first ASID Contract Design Award winner.

Advanced BeautyGard® protective top coat finish is produced from environmentally friendly materials and processes and is technically formulated to achieve the highest performance standards.
Recommended Applications
Residential
Office
Hospitality
Truck/Bus
Auto Trim
Medical/Dental



Naugahyde Phoenix Specifications:
Naugahyde® continues its tradition in FR* vinyl coated fabrics with the introduction of Phoenix. This Naugahyde 2-200 Flame Blocker product is designed to be used in high fire risk public access installations.

Phoenix combines state of the art technology with a full range of thirty colors designed to complement contract carpet, wall covering and laminate products. Included in this palette are traditional, emerging traditional, and new hues to satisfy the designer's demand for color.

Chairs upholstered with Naugahyde 2-200 Flame Blocker can meet the full scale burn requirements of the Boston Fire Department Chair Test and those of California Technical Bulletin 133 under certain conditions.

Product Features
* Sulfide stain resistant (hospitals, nursing homes & hair salons)
* BeautyGard® protective finish
* Cleans easily with mild soap and water
* -20º cold crack
* 54" wide
* Antistatic slip finish

Disinfectability
Naugahyde with Advanced BeautyGard® has been formulated to achieve a superior level of disinfectability with disinfectant products containing sodium hypochlorite (common household bleach) diluted 1:10.

Serviceability
Naugahyde with Advanced BeautyGard® provides outstanding protection in difficult medical and healthcare environments.  This product contains agents to protect it against bacterial and fungal micro-organisms.

Flammability
Naugahyde 2-200 Flame Blocker is formulated to have smoke emission less than 200 (ASTM E662) and to meet flammability* requirements contained in these specifications:
California Fire Regulation (Bulletin 117, Sec. E)
Automotive (MVSS302)
BIFMA (Screen Test, Sec. 4.6.1.1)
Boston Fire Code (BFD IX1)
CID AA2950A (Federal Standard 191A test method 5903) replaces CCCA680a
Upholstery Requirements of FAR 25.853
Port Authority of NY and NJ.

Recommended Applications
Office, Hair Salons, Hotel / Motel, Auditorium seating, Restaurant, Hospital, Dormitory, Nursing home, Prison, Subway, Train, Bus seating and interiors.



*This term and any corresponding data refer to typical performance in the specific tests indicated and should not be construed to imply the behavior of this or any other material under other fire conditions.

**The Cal-133 test is highly dependent on chair construction and each specific construction musts be tested for compliance. The above results were obtained on stack chain with melamine polyurethane foams or HR Cal 117 foams and tub chain with melamine polyurethane foams. Detailed test results are available upon request. Melamine polyurethane foams generally are preferred with Flame Blocker.

***When used with melamine polyurethane foam or Hit polyurethane foam which meets California bulletin #117 requirements. All data regarding Naugahyde 2.200 Flame Blocker fabric was obtained using specific test methods under controlled laboratory conditions to measure performance against codes or specifications. Details of test results an, available upon request. While Uniroyal views the product as a significant Improvement over existing technology, all organic materials will bum and generate smoke under some fire conditions.
